Features
Images real-time display, one button magnifying
Non-mydriatic and high definition imaging.
Micro SD memory card up to 80,000 images
USB and WiFi connection
Low weight 450g , movable and portable
Rechargeable battery provides up to more than 5 hours of continuous operation.
|
Product Type
|
Non-mydriatic, Portable
|
|
FOV
|
50°
|
|
Sensor resolution
|
10 million/12 million pixels
|
|
Optical resolution
|
>60lp/mm
|
|
Fixation Lamp
|
Fixation within 5 points (with center fixation)
|
|
Minimum pupil diameter
|
2.5mm
|
|
Working distance
|
24mm
|
|
Light Source
|
White LED & Infrared LED
|
|
Focus
|
Manual/Auto
|
|
Focus range
|
|
|
Display
|
4.7-inch multi-touch screen (anti-glare)
|
|
Image format
|
jpg(Picture);MPEG-4/1(Video);DICOM3.0
|
|
Imaging mode
|
Color image, monochrome image, infrared image
|
|
Synchronous display
|
Compatible with HDMI and USB dynamic video output;
Device & PC dual-screen simultaneous display (USB cable, HDMI cable, wireless);
Device & TV dual screen simultaneous display (network, wireless)
|
|
RAM
|
4G+64G
|
|
GHz
|
4 core @2.2GHz
|
|
Data transmission
|
USB3.0, WiFi, SD card storage, HDMI, wireless transmission adapter
|
|
4G function
|
Available
|
|
NFC function
|
ID card recognition
|
|
Camera button
|
Front photo button, touch photo button,focus dial button
|
|
Working time(Fully charged)
|
＞6 Hours
|
|
Battery Charging time
|
＜2 Hours
|
|
Power Supply
|
3.7V lithium battery 3500mAH
|
|
Charging requirements
|
100~240VAC,50/60Hz
|
|
Power Adapter
|
5V DC, 2A
|
|
Product Dimensions
|
＜205mm×125mm×205mm(L/W/H)
|
|
Net Weight
|
＜450g
|
|
Packing List
|
Device Main Body, charging base, eyecup, dust cover, power adapter, USB3.0 data cable, American standard European standard
conversion plug (optional), 2 batteries, 3 pieces of lens cleaning paper, Product manual, software U disk
|
